Test No. | Test Name | Result-1 | Test Method | Required as Per IS |
---|---|---|---|---|
1. | Specific Gravity | 2.58 | IS: 2386:3:1963 | -- |
2. | Water Absorption % | 0.52 | IS: 2386:3:1963 | Max 2% (As per MORTH) |
3. | Impact Value % | 11.45 | IS: 2386:4:1963 | Max 30% (For Wearing Surface) Max 45%(For other than Wearing) |
4. | Flankiness + Elongation Index % | 16.89 | IS: 2386:1:1963 | For Combined FI & EI Index Max 30% |
5. | Abrasion Value % | 12.01 | IS: 2386:4:1963 | Max 40% for WBM%, Max 35% for DBM% |
6. | Porosity | 22% | Max 46% | |
7. | Bulk Density | 1465 kg/ M3 | 1400 Kg/ M3 | |
8. | Water Absorption | 0.60% | 2.0% Max | |
9. | Compressive Strength | 92.0 | 85.0 Mpa |
Sieve Size in mm | % Passing | ||
---|---|---|---|
G-1 | G-2 | G-3 | |
12.5 | 100% | ||
10 | 94.8% | ||
4.75 | 12.5% | ||
2.36 | 1.2 |
Capacity: 1,000,000 MT/Year
